FPC Separator

V Groove PCB Depanelizer PCB Separator

T Longest Minimize: 450mm
Size:620mm X 350mm X 400mm
Minimize thickness:0.3-3.5mm
Machine Weight:200kg
Product description: V Groove PCB Depanelizer PCB Separator
INQUIRY

V Groove PCB Depanelizer PCB Separator Feature:

●Separates boards up to 3.5mm thick
●Shears boards safely with parts as close as 0.5mm to the
score line,including ceramic capacitors
●Operator foolproof! Panels cannot be inserted into the
knives except on the score line
●Pneumatically driven
●Handles high components up to70mm
●Bow waves that can occur with round knives are avoided
●Easy adjusting of distance between knives
●Independent lab tests show less than 200 microstrains of
stress measuring compression and tension.
●Has capacity counter function

V Groove PCB Depanelizer PCB Separator Specification:
Model: CWVC-450J
The Longest Minimize: 450mm
Size: 960×425×350mm
Minimize thickness: 1.0-3.5mm
Machine Weight: 200KG

PCB separator,CWVC-450J Our Service:
# 1 day delivery
# 24 hours fast response
# Largest manufactory in South China
# 100% responsible for quality
# 18 years experience
# Free sharpening for blades within 3 months
